This equipment is a special equipment for the preparation of metal materials. It is mainly used for colleges, universities and scientific research institutions to treat metal materials (such as stainless steel, nickel-based alloys, copper, alloy steel, nickel-cobalt alloys, rare earth neodymium-iron alloys, etc.) under vacuum or protective atmosphere conditions. Etc.) melting treatment, vacuum refining treatment and precision casting of alloy steel can also be carried out. This equipment uses a temperature control instrument to control the power supply heating, and the temperature measurement uses a platinum rhodium thermocouple or an infrared meter to measure the temperature, the temperature is more accurate and energy-saving
1.The melting speed is fast(Smelt in about 15 minutes), the temperature can reach 2000℃ when the insulation jacket is installed
2.Optional program heating and temperature control, set the heating or cooling curve according to your process requirements, and the equipment will automatically heat or cool according to this process
3.It can be smelted under a variety of atmosphere conditions: smelting under air, protective atmosphere and high vacuum conditions. Buy a device to achieve multiple functions; it saves your cost to a degree.
4.Optional secondary feeding system: It can add other elements in the melting process, which is convenient for you to prepare diversified samples
5.The furnace body is all stainless steel structure, and with water cooling, to ensure that the temperature of the shell is lower than 35 ℃, to protect your personal safety
| Model | Max Temperature | Power(kw) | Vacuum | Capacity |
| DM-VIF0.2 | 2100℃ | 7 | 5pa | 0.2kg |
| DM-VIF0.5 | 2100℃ | 15 | 5*10-3pa | 0.5kg |
| DM-VIF1 | 2100℃ | 25 | 5*10-3pa | 1kg |
| DM-VIF2 | 1750℃ | 30 | 5*10-3pa | 2kg |
| DM-VIF3 | 1750℃ | 35 | 5*10-3pa | 3kg |
| DM-VIF5 | 1750℃ | 45 | 5*10-3pa | 5kg |
| DM-VIF10 | 1750℃ | 65 | 6.7*10-3pa | 10kg |
| DM-VIF25 | 1750℃ | 100 | 6.7*10-3pa | 25kg |
| DM-VIF50 | 1750℃ | 160 | 6.7*10-3pa | 50kg |
| DM-VIF100 | 1750℃ | 200 | 6.7*10-3pa | 100kg |
| Can Be Customized | ||||
